| Technical Specification | Unit | MB523F | MB524F |
| Max. planing width | mm | 300 | 400 |
| Max. planing depth | mm | 4 | 5 |
| Spindle speed | r/min | 5600 | 5000 |
| Blade number | / | 3 | 4 |
| Cutting diameter | mm | Ø87 | Ø102 |
| Workbench total length | mm | 1800 | 2500 |
| Motor power | kW | 2.2 | 3.0 |
| Motor speed | r/min | 2840 | 2880 |
| Overall dimensions | mm | 1800×740×1010 | 2500×810×1050 |
| Net.weight | kg | 300 | 440 |
