| Technical Specification | Unit | MH1725A | MH1725 |
| Max. composing width | mm | 1250 | 1250 |
| Max. composing length | mm | 2500 | 2500 |
| Workpiece thickness | mm | 15-90 | 15-90 |
| Number of composing rows | 6 | 14 | |
| Motor power | kW | 1.5 | 1.5 |
| Main spindle speed | r/min | 2 | 2 |
| Working air pressure | MPa | 0.4-0.8 | 0.4-0.8 |
| Overall dimensions | mm | 3860×3315×3787 | 4480×3315×3787 |
|
Net.weight |
kg |
2030 |
4150 |
